Product Details:
|
| Automatic Grade: | Automatic | Name: | Hot Stamping Machine |
|---|---|---|---|
| Type: | Logo Printing | Driven Type: | Electric |
| Min Hot Stamping Size: | No Fix | Max Hot Stamping Size: | 200*160 |
| High Light: | Hot Stamping Logo Printing Machine,Hot Stamping Machine,Hot Stamping Logo Machine |
||
Full Automatic Hot Stamping Logo Machine
Technical Parameter
| MODEL | WM-TY2016 |
| LENGTH | W100-550MM |
| WIDTH | W100-500MM |
| PAPER THICKNESS | 80-350GSM |
| Max.Hot Stamping Size | 200mm*160mm |
| Min.Hot Stamping Size | No fix |
| WORKING SPEED | 20-36PCS/MIN |
| POWER | 1KW |
| AIR PRESSURE | 0.5-0.8MPa |
| VOLTAGE | 220V/50HZ |
| MACHINE WEIGHT | 800KG |
| MACHINE SIZE | 2200*1200*1600MM |
Machine Features :
1.Full automatic paper feeder and receiving.
2. Independent paper separation mechanism to ensure single sheet operation.
3. Servo paper feeding mechanism, high precision and efficiency
4. Intelligent digital temperature control, automatic constant temperature, uniform heating.
5. The servo pressure is large and stable and efficient
6. High temperature resistant silica base plate makes hot stamping better.
Product Application
Packing
Our Service
1. Pre-Sales Service:
Inquiry and consulting support.
Sample testing support.
View our Factory.
2. After-Sales Service
Training how to install the machine, training how to use the machine.
Engineers available to service machinery overseas.
3. Warranty
We provide 12 months warranty. During warranty, we provide free technical support and free normal spare parts for replacing, except for man-made damage. We can go to your country to debug machine when you have questions can not resolve, but you must pay 100usd/day to our engineer.
Look forward to long term cooperation with customers, we will make best service and after sales service for all of our customers.
