Full Automatic Hard Case Making Machine / Automatic Positioning Gluing Machine

Basic Information
Place of Origin: CHINA
Brand Name: WELLMARK
Certification: CE
Model Number: WM-HC800
Minimum Order Quantity: 1 SET
Price: Negotiable
Packaging Details: Wooden Case
Delivery Time: 5-8 working days
Payment Terms: L/C, T/T
Supply Ability: 1 set per 15 working days
Detail Information
Automatic Grade: Automatic Packaging Type: Case
Driven Type: Electric,Mechanical Application: Machinery & Hardware
After-sales Service Provided: Video Technical Support Warranty: 12 Months
Product Name: Corrugated Cardboard Glue Making Machine Price Name: High Quality Automatic Corrugated Carton Folding Gluing Machine
High Light:

35pcs/Min Hard Case Making Machine

,

18KW Motor Hard Case Making Machine

,

Automatic Positioning Gluing Machine


Product Description

Full Automatic Hard Case Making Machine / Automatic Positioning Gluing Machine







Features and function configuration



1. Suitable for all kinds of quare hard book case to automatic production

2. Automatic clamp grey board leading device

3. Computer control with error auto stop and display

4. Automatically feed paper and greyboard

5. 24-hours control for glue pre-heating

6. Spotter by 2pcs of 5 megapixel HD Camera tracing system and Yamaha mechanical arm to positioning (spotting accuracy ≤0.1mm

7. Folder can automatically and continually foldling four side and pressing.

8. Automatic control system for hot glue viscosity(optional).



Product Flew



Fully Automatic Hard Case Making Machine For High - End Electronic Boxes 0



Product Application

Full Automatic Hard Case Making Machine / Automatic Positioning Gluing Machine 1  Full Automatic Hard Case Making Machine / Automatic Positioning Gluing Machine 2

Product Advantage



1, the automatic shell machine generally adopts feida automatic paper feeding structure, the whole movement is pneumatic control, the structure is simple and reasonable.

2. The width adjustment of the stack platform and the paper platform adopts the center concentric adjustment, and the operation is simple without error.

3, the cardboard feeding table adopts linear guide rail, accurate.

4. There is an automatic stop device for the paperboard feeding table to reduce the rejection rate of good products.

5. The conveyor belt adopts high-power suction fan, which makes the paper transportation more stable and accurate.

6. The paper conveying and positioning system adopts imported high-precision photoelectric control, making the positioning of paper and paperboard more accurate and reliable.

7. The rear automatic four-side dismantling machine adopts unique automatic pressure Angle and blanking mechanism to ensure the qualified rate of finished products.

8. The automatic leather shell machine material collecting platform adopts the desktop stacking conveying and discharging, which is more convenient for material receiving



Technical Parameter





Paper Wrap Size

(L=Length,W=Width)

Widest(W) 630mm
Narrowest(W) 100mm
Longest(L) 820mm
Shortest(L) 120mm





Hard Book Case Size

L=Length W=Width



Longest(L) 800mm
Shortest(L) 180mm
Widest(W) 450mm
Narrowest(W) 120mm
Thickness of Paperboard(g/m2) Thinnest(T) 1.0mm -4.0mm

Thickness of Paper(g/m2,) Range 80g/m2-200g/m2
Speed ≤35pcs/min
Air pressure 6-8bar
Voltage 380V/50HZ
Moter power 18kw
Heater power 6kw
Net Weight 5800kgs
Machine Overall Dimension L6.5m×W4.3m×H2.2m



Our Exhibitions



We attended at least three oversea exhibitions every year to show our products to clients, warmly welcome to visit our booth in the exhibitions.



Full Automatic Hard Case Making Machine / Automatic Positioning Gluing Machine 3

Frequently Asked Questions



Q1. What is your terms of packing?
A: Generally, we pack our goods in plywood box. Suitable for exporting.

Q2. What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos and video of the products and packages before you pay the balance.

Q3. What is your terms of delivery?
A: EXW, FOB, CIF.

Q4. How about your delivery time?
A: Generally, it will take 7 to 15 days after receiving your down payment. The specific delivery time depends on the items and the quantity of your order.

Q5. Can you produce according to my requests?
A: Yes, we can produce according to your requests. We can design and develop the machine.

Q6. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery

Q7: How do you make our business long-term and good relationship?
A:1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
