Product Details:
|
| Brand Name: | Wellmark | Function: | Box Forming |
|---|---|---|---|
| Voltage: | 220V/50HZ | Power: | 1.5kw |
| Dimension: | L120*W150*H220cm | Weight: | 1080kgs |
| Change Mould Time: | 5-10min | Warranty: | 1 Year |
| Highlight: | wrapping machine for boxes,perfume box wrapping machine,rigid box forming machine |
||
Automatic Rigid Box Wrapping Machine For Rigid Box Forming
Automatic Rigid Box Forming Machine catalog.pdf
Product Description
WM-500A Automatic Fast Change Moulds Machine is our company's latest research and development of full automatic intelligence box molding machines.it’s specialized in mass producing all kinds of rigid boxes or plastic boxes, such as finest jewelry boxes, ornaments boxes, gift boxes, watch boxes, pencil boxes, candy boxes, souvenir boxes, and cosmetic boxes, etc.
This machine is our company's latest research and development of full automatic intelligence box forming machines.it’s specialized in mass producing all kinds of rigid boxes or plastic boxes, such as finest jewelry boxes, ornaments boxes, gift boxes, watch boxes, pencil boxes, candy boxes, souvenir boxes, and cosmetic boxes, etc.
Techical Parameters
| Model | WM-500A | |
| Box Size | Longest | 500mm |
| Shortest | 80mm | |
| Widest | 400mm | |
| Narrowest | 60mm | |
| Highest | 120mm | |
| Lowest | 12mm | |
| Thickness of paperboard | Range | 1-3mm |
| Thickness of paper | Range | 80g-300g |
| Folding Edge Inside size | Range | 10-70mm |
| Folding Ears size | Range | 10-100mm |
| Speed | ≦20pcs/min | |
| Air Pressure | 0.6-0.8MPa | |
| Voltage | 220V/50HZ | |
| Moter Power | 1.5KW | |
| Net Weight | 1080kgs | |
| Machine Overall Dimension | L120*W150*H220cm | |
Product Features
This machine adopts PLC and man-machine control, error auto stop and display,it use air cylinder and double servo and stepper control ,all the parts adopt international high-end brands,low failure rate,high precision,fully automated process,this machine no need change the pressure board,folding knife,just input the dimensions size of box,the machine will adjust the size automatically,save the time of change the different size ,it automatically wrap box, fold corner edges and wrapping box, it has small volume,easy to operate ,fast speed,change size more simple ect.
Advantages
a, Very simple to operate, quickly change model and set machine
b, PLC touch screen, very simple to use, can set the quantity and record quantity which be made.
c, Double servo motors to make accurate forming.
d, Forming and pressure bubble together, do not need to pressure bubble again after forming.
e, Has four forming types can choose, suitable for making special box.
f, Use imported bearings and electronic components, making stable and longer uselife.
g, Add a air container to make the air pressure in one level all the time, This will help to avoid damge machine because the unstable air pressure.
Our Services
We provide 12 months warranty. During warranty, we provide free technical support and free normal spare parts for replacing, except for man-made damage.We can go to your country to debug machine when you have questions can not resolve,but you must pay 100usd/day to our engineer.
Look forward to long term cooperation with customers, we will make best service and aftersales service for all of our customers.
Frequently Asked Questions
Q1. What is your terms of packing?
A: Generally, we pack our goods in plywood box. Suitable for exporting.
Q2. What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos and video of the products and packages before you pay the balance.
Q3. What is your terms of delivery?
A: EXW, FOB, CIF.
Q4. How about your delivery time?
A: Generally, it will take 7 to 15 days after receiving your down payment. The specific delivery time depends on the items and the quantity of your order.
Q5. Can you produce according to my requests?
A: Yes, we can produce accordint to your requests. We can design and develop the machine.
Q6. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery
Q7: How do you make our business long-term and good relationship?
A:1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
