Rigid Box Corner Pasting Equipment For Pasting Box Four Corner

Rigid Box Corner Pasting Equipment For Pasting Box Four Corner
Rigid Box Corner Pasting Equipment For Pasting Box Four Corner Rigid Box Corner Pasting Equipment For Pasting Box Four Corner Rigid Box Corner Pasting Equipment For Pasting Box Four Corner Rigid Box Corner Pasting Equipment For Pasting Box Four Corner

Large Image :  Rigid Box Corner Pasting Equipment For Pasting Box Four Corner

Product Details:
Place of Origin: CHINA
Brand Name: WELLMARK
Certification: SGS
Model Number: WM-40A
Payment & Shipping Terms:
Minimum Order Quantity: 1PCS
Price: Negotiable
Packaging Details: Wood Case
Delivery Time: 5-8 work day
Payment Terms: T/T, L/C at sight
Supply Ability: 30pcs/month

Rigid Box Corner Pasting Equipment For Pasting Box Four Corner

Description
Product Type: Paper Box Making Machine Automatic Grad: Automatic
Place Of Origin: Guangdong, China (Mainland) Brand Name: WELLMARK
Model Number: WM-40A Application: Corner Pasting
Packaging Type: Wood Case Dimension(L*W*H): L2000 X W1180 X H1970MM
After-sales Service Provided: Engineers Available To Service Machinery Overseas Warranty: 1 Year
High Light:

fully automatic rigid box making machine

,

automatic rigid box machine

,

automatic gift box making machine

Rigid Box Corner Pasting Equipment For Pasting Box Four Corner

Automatic Corner Pasting Machine Catalog.pdf







Product Advantage



1. The time of sticking angle is as short as 0.1 seconds, and the fastest speed of sticking angle is 5000 per hour.e.
2. Adjust the grey board size is very simple with fast time.
3. Adjusting the length of the tape is also very convenient and fast.

4. Adjust the box size for pasting are convenient and fast.
5. High speed automatic feeding the grey board and automatic pasting the four corner in once time finished.

6. Use moulds to postion the rigid box to automtic pasting the box corner by high speed.
7. With auxiliary carton forming device, it is convenient for all kinds of cartons to stick corners perfectly.

8. Replacement of cartons and moulds of different sizes is simple and fast.





Rigid Box Product flew



Rigid Box Corner Pasting Equipment For Pasting Box Four Corner 0





Product Application



This machine use for pasting box corner of all kind rigid boxes .



Rigid Box Corner Pasting Equipment For Pasting Box Four Corner 1



Other Product Recommend



Corner Stay Tape





Techical Parameters



MODEL WM-40A
WORKING SPEED 30-90pcs/min
MAX.SIZE OF BOX 400*300*120mm
MIN.SIZE OF BOX 40x40x10mm
POWER 2.0KW
AIR PRESSURE ≧0.6Mpa
POWER SUPPLY 220V/50HZ
MACHINE SIZE L2000 X W1180 X H1970MM
MACHINE WEIGHT 1000KG







Product Description


Automatic Four Corner Pasting Machine WM-40A is the best equipment to produce high-grade rigid boxes. Reasonable design, stable performance, equivalent to the international leading technology level. Adopt PLC programmable controller,high speed belt to feeding the grey board by automatic , touch human-machine interface. Realize the automatic grey board sending and pasting the four corner with hotmelt tape by moulding of one-time finish. The machine production efficiency is several times higher than that of the traditional craft production, also have fault diagnosis display and alarm function, operation safety guarantee. Suitable for making the high-quality goods class electronic box, jewelry box, and other high-grade packing gift box cover heaven and earth.


Product Feature


1. The length of adhesive tape can be adjusted between 10-50mm length by once for the different boxes.

2. The machine can use various hot-melt adhesive tape, the width is usually 19mm.other width of tape have to special to make it .
3. The mainshaft adopts servo motor to drive the gear guide rail, making sure every accurate movement.

4. All electric parts are from famous brand, low error and high precision.

5. Grey Boards are fed from bottom, thus no need to stop the machine for adding boards.

6. The machine adopts single arm press device and thermostatic temperature control system.

7. With malfunction alarm and fault display.

8. Operated by touch screen, with both Chinese and English by one switch.

9. Stepper motors feed hot melt tapes which are pasted onto 4 corners at the same time

10. the machine simple operation, fast working speed, high production efficiency, high cost performance.





Safety precautions



1. Compliance with safety precautions during production can prevent accidents and potential hazards.

2. When problems are found, please solve them in time. We can't continue production without problems.

3. Please designate professionals to train on-the-job operation and maintenance equipment.

4. Verify whether the equipment is in normal condition before the equipment is running, such as checking the air pressure, resetting the mould, etc.

5. Before production, please wear labor protection equipment to ensure the health and safety of operators.

6. The equipment can not touch any rotating parts and movable parts in the operation process, so as to avoid causing personal injury.

7. Keep all air passages open.

8. It is forbidden to touch the high-temperature head-mounted parts by hand after being heated by electricity.

9. No touch adjustment is allowed when the equipment is running.



Our Exhibitions



We attended at least three oversea exhibitions every year to show our products to clients, warmly welcome to visit our booth in the exhibitions.



Rigid Box Corner Pasting Equipment For Pasting Box Four Corner 2



Packing and Shipping

Packaging by wooden case and shipping by containers.



Rigid Box Corner Pasting Equipment For Pasting Box Four Corner 3
