Automatic Rigid Box Making Machine / Paper Box Making Machine

Basic Information
Place of Origin: CHINA
Brand Name: WELLMARK
Certification: CE
Model Number: WM-4045A/B
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: wooden case
Delivery Time: 5-8 workdays
Payment Terms: L/C, T/T
Supply Ability: 1 set per 15 working days
Detail Information
Warranty: One Year After-sales Service Provided: Video Technical Support
Automatic Grade: Automatic Type: Boxing Machine
Color: Customized Color Product Name: Automatic Rigid Box Making Machine Paper Box Forming Machine
Driven Type: Electric&pneumatic Function: Box Making
High Light:

PLC Paper Box Forming Machine


18kw Paper Box Making equipment

Product Description

Automatic Rigid Box Making Machine / Paper Box Making Machine



Product Description


Full Automatic Rigid Box Making Machine is the best equipment to produce high-grade products cover the boxes. Reasonable design, stable performance ,equivalent to the international leading technology level, Adopt PLC programmable controller, HD Camera positioning system , YAMAHA mechanical arm to positioning, touch human-machine interface. Realize the automatic paper, automatic gluing, automatic positioning, artificial boxes automatically fold the ear side pressure foam molding process action series of one-time finish.


In feida, gluing and conveyor belt using well-known brand servo drive, stepless variable speed, high precision, easy to adjust, save time; Image positioning system and robot grasping parts are adopted in the corner and positioning part to improve positioning accuracy and efficiency. The error range is up to ±0.05mm, and the positioning and debugging speed is faster. The machine adopts THK linear guide rail and virtual electronic CAM drive, which is more stable and wear-resistant and moves more smoothly, with a larger size range of folding depth and folding length.


The machine production efficiency is several times higher than that of the traditional craft production, also have fault diagnosis display and alarm function, operation safety guarantee. Suitable for making the high-quality goods class electronic box, jewelry box, and other high –grade packing gift box cover heaven and earth.( It is suitable for the mass production of various boxes, such as mobile phone boxes, jewelry boxes, cosmetic boxes, watch boxes and so on. Make a wider range of boxes. More to meet the needs of the modern packaging market. The appearance of the machine after a new design, more safe and beautiful.)


Note: the maximum size of the box and minimum size depend on the paper at the same time the maximum and minimum size and surface quality of the paper. Speed will depending on the different boxes size with different paper materials.



Technical Parameter



Paper Wrap Size

(L=Length, W=Width)

Widest(W) 630mm
Narrowest(W) 95mm
Longest(L) 820mm
Shortest(L) 120mm



Box Size

L=Length W=Width


Longest(L) 450mm
Shortest(L) 100mm
Widest(W) 400mm
Narrowest(W) 85mm
Highest(H) 120mm
Shortest(H) 15mm
Thickness of Paperboard(g/m2) Thinnest(T) 1.0mm - 4.0mm
Thickness of Paper(g/m2) Range 80g/m2-300g/m2
Speed ≤32pcs/min
Air pressure 0.6-0.8MPa
Voltage 380V/50HZ
Power 18kw
Net Weight 5800kgs
Machine Overall Dimension L7.3m×W4.3m×H3.1m























1, The machine automatic feeding paper and gluing, automatic feeding grey board , manipulator taking box positioning, mechanical arm holding box forming and pressing air bubbles an intelligent production line is completed.

2, 24-hours control for glue pre-heating function

3, Spotter by 2pcs of 5 megapixel HD Camera tracing system and YANAHA mechanical arm to positioning (spotting accuracy≤0.1mm)

4,The automatic corner pasting is controlled by heating alone

5,The forming part of boxes is accomplish intelligently with mechanical arm holding box, edge wrapping, ear folding, folding-in and air bubbles pressing.

6, The whole machine adopts PLC control, HD Camera positioning system , touch human-machine interface, the automatic production of rigid boxes forming process.

7, Computer control with error auto stop and display

8, Automatic Control System of Glue Viscosity (Selection)

9,The Forming unit can choose one or two (Selection)

10,Do not need to replace the shovel knife, pressing plate.

11, With memory function, fast version.


Rigid Box Product flew


Automatic Rigid Box Making Machine / Paper Box Making Machine 0

Our Exhibitions


We attended at least three oversea exhibitions every year to show our products to clients, warmly welcome to visit our booth in the exhibitions.

Automatic Rigid Box Making Machine / Paper Box Making Machine 1


Our Services


1. Pre-Sales Service:

Inquiry and consulting support.
Sample testing support.
View our Factory.


2. After-Sales Service

Training how to install the machine, training how to use the machine.
Engineers available to service machinery overseas.


3. Warranty

We provide 12 months warranty. During warranty, we provide free technical support and free normal spare parts for replacing, except for man-made damage. We can go to your country to debug machine when you have questions can not resolve, but you must pay 100usd/day to our engineer.

Look forward to long term cooperation with customers, we will make best service and after sales service for all of our customers.
