|Product Type:||Paper Box Making Machine||Automatic Grad:||Automatic|
|Place Of Origin:||Guangdong, China (Mainland)||Brand Name:||WELLMARK|
|Model Number:||WM-SJT40||Application:||Corner Pasting|
|Packaging Type:||Wood Case||Dimension(L*W*H):||L2000 X W1180 X H1970MM|
|After-sales Service Provided:||Engineers Available To Service Machinery Overseas||Warranty:||1 Year|
automatic paper box making machine,
fully automatic carton box making machine
Automatic Rigid Box Making Machine For Corner Pasting
Automatic Corner Pasting Machine Catalog.pdf
WM-40A Automatic Four Corner Pasting Machine is the best equipment to produce high-grade rigid boxes. Reasonable design, stable performance, equivalent to the international leading technology level. Adopt PLC programmable controller,high speed belt to feeding the grey board by automatic , touch human-machine interface. Realize the automatic grey board sending and pasting the four corner with hotmelt tape by moulding of one-time finish. The machine production efficiency is several times higher than that of the traditional craft production, also have fault diagnosis display and alarm function, operation safety guarantee. Suitable for making the high-quality goods class electronic box, jewelry box, and other high-grade packing gift box cover heaven and earth.
1. Adjust the box size for pasting are convenient and fast.
2. The time of sticking angle is as short as 0.1 seconds, and the fastest speed of sticking angle is 5000 per hour.e.
3. With auxiliary carton forming device, it is convenient for all kinds of cartons to stick corners perfectly.
4. High speed automatic feeding the grey board and automatic pasting the four corner in once time finished.
5. Adjusting the length of the tape is also very convenient and fast.
6. Use moulds to postion the rigid box to automtic pasting the box corner by high speed.
7. Adjust the grey board size is very simple with fast time.
8. Replacement of cartons and moulds of different sizes is simple and fast.
|MAX.SIZE OF BOX||400*300*120mm|
|MIN.SIZE OF BOX||40x40x10mm|
|MACHINE SIZE||L2000 X W1180 X H1970MM|
Rigid Box Product flew
Hot Melt Tape
1. The machine adopts single arm press device and thermostatic temperature control system.
2. The machine can use various hot-melt adhesive tape, the width is usually 19mm.other width of tape have to special to make it .
3. The length of adhesive tape can be adjusted between 10-50mm length by once for the different boxes.
4. the machine simple operation, fast working speed, high production efficiency, high cost performance.
1. Compliance with safety precautions during production can prevent accidents and potential hazards.
2. Please designate professionals to train on-the-job operation and maintenance equipment.
3. When problems are found, please solve them in time. We can't continue production without problems.
4. Before production, please wear labor protection equipment to ensure the health and safety of operators.
5. Verify whether the equipment is in normal condition before the equipment is running, such as checking the air pressure, resetting the mould, etc.
6. The equipment can not touch any rotating parts and movable parts in the operation process, so as to avoid causing personal injury.
7. Keep all air passages open.
8. It is forbidden to touch the high-temperature head-mounted parts by hand after being heated by electricity.
9. No touch adjustment is allowed when the equipment is running.
We attended at least three oversea exhibitions every year to show our products to clients, warmly welcome to visit our booth in the exhibitions.
Packing and Shipping
Packaging by wooden case and shipping by containers.
