Product Details:
|
Type: | Packaging Machine | Application: | Phone Box, Gift Box |
---|---|---|---|
Automatic Grade: | Autoamtic | GlueType: | Hot Glue |
Tape Type: | PET Tape | Packaging Detail: | Wooden Case |
Weight: | 5800kg | Power: | 18kw |
Highlight: | fully automatic rigid box making machine,automatic rigid box machine,automatic gift box making machine |
Full Automatic Rigid Box making Machine For Packing Gift Box
Product Description
Full Automatic Rigid Box Making Machine is the best equipment to produce high-grade products cover the boxes. Reasonable design, stable performance ,equivalent to the international leading technology level, Adopt PLC programmable controller, HD Camera positioning system , YAMAHA mechanical arm to positioning, touch human-machine interface. Realize the automatic paper, automatic gluing, automatic positioning, artificial boxes automatically fold the ear side pressure foam molding process action series of one-time finish.
The machine production efficiency is several times higher than that of the traditional craft production, also have fault diagnosis display and alarm function, operation safety guarantee. It is suitable for the mass production of various boxes, such as mobile phone boxes, jewelry boxes, cosmetic boxes, watch boxes and so on. Make a wider range of boxes. More to meet the needs of the modern packaging market. The appearance of the machine after a new design, more safe and beautiful.
Technical Parameter
Model | WM-4045A |
Widest(W) | 630mm |
Narrowest(W) | 95mm |
Longest(L) | 820mm |
Shortest(L) | 120mm |
Longest(L) | 450mm |
Shortest(L) | 100mm |
Widest(W) | 400mm |
Narrowest(W) | 80mm |
Highest(H) | 120mm |
Shortest(H) | 15mm |
Thickness of Paperboard(T) | 1.0mm-4.0mm |
Thickness of Paper(g/㎡) | 80g/㎡-300g/㎡ |
Speed | ≤32pcs/min |
Air pressure | 0.6-0.8MPa |
Voltage | 380V/50Hz |
Power | 18Kw |
Weight | 5800Kg |
Machine Size | L7300*W4300*H3100mm |
Rigid Box Product flew
Production Application
(The machine use for all kind of rigid boxes)
Packing and Shipping
Packaging by wooden case and shipping by containers.
