Semiautomatic Air Bubbles Press Machine

Basic Information
Place of Origin: CHINA
Brand Name: WELLMARK
Certification: CE
Model Number: WM-ZP515
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Wooden case
Delivery Time: 5-8 workdays
Payment Terms: L/C, T/T
Supply Ability: 1 set per one week
Detail Information
Usage: Air Bubbles Pressing Max Size Of Box: 500*500*150mm
Min Size Of Box: 80*45*15mm Speed: <20pcs/min
Power: 1.2KW Voltage: 220V/50Hz
High Light:

automatic paper box making machine

,

food box making machine


Product Description

Semiautomatic Air Bubbles Press Machine





Product Features



1. Very simple to operate, quickly change model and set machine

2. PLC touch screen, very simple to use, can set the quantity and record quantity which be made.

3. Double servo motors to make accurate forming.

4. Folding inside and pressure bubble together, do not need to pressure bubble again after forming.

5. Has two pressing types can choose, suitable for making special box.

6. Use imported bearings and electronic components, making stable and longer uselife.

7. Add a air container to make the air pressure in one level all the time, This will help to avoid damage machine because the unstable air pressure.

8. Fully automatic production, five-sided press box

9. Extremely fast and efficient shaping, automatic counting

10. Step-by-step control of conveyor belt without scratch

11. Feed conveyor belt height is adjustable and adaptable.



Product Description



Bubble press is a new type of flattening correction equipment specially used to solve the problems of air bubbles, package, folds and deformations on the bonding surface of cartons after making and molding. The invention of foam press solves the problem of slow, labor-intensive and rough precision in traditional manual scraping and rubbing. The use of the foaming machine ensures the excellent characteristics and accuracy of the carton after forming.



Product Application



Semiautomatic Air Bubbles Press Machine 0



Technical Parameter



Model WM-ZP515
Longest(L) 60-500mm
Widest(W) 40-400mm
Highest(H) 12-120mm
Power 1.2kw
Speed ≤20pcs/min
Air Pressure 0.6-0.8MPa
Voltage 220V/50Hz
Machine Size L1000*W1000*H2600mm



Our Exhibitions



We attended at least three oversea exhibitions every year to show our products to clients, warmly welcome to visit our booth in the exhibitions.

Semiautomatic Air Bubbles Press Machine 1
