Product Details:
|
| Voltage: | 220V/50Hz | Condition: | New |
|---|---|---|---|
| Warranty: | One Year | After-sales Service Provided: | Engineers Available To Service Machinery Overseas |
| Automatic Grade: | Automatic | Product Name: | Automatic Rigid Box Making Machine Paper Box Corner Pasting Machine |
| High Light: | fully automatic rigid box making machine,automatic rigid box machine,automatic gift box making machine |
||
Suction Board Type Feeding Grey Board Automatic Rigid Box Corner Pasting Machine
Product features:
1, The machine adopts single arm press device and thermostatic temperature control system.
2, The machine can use various hot-melt adhesive tape, the width is usually 19mm. other width of tape have to special make it.
3, The length of adhesive tape can be adjusted between 10-60mm length by once for the different boxes.
4, The machine simple operation, fast working speed, high production efficiency, high cost performance.
5, This machine adopts suction board type feeding grey board, double table replacement paperboard.
Rigid Box Product Flew
Other Product Recommend
Hot Tape / Hot Melt Tape / PET Tape
Technical Parameter
| Model | WM-SJT460 |
| Grey Board Thickness | 1-3mm |
| Max Length of Box | 500mm |
| Min Length of Box | 50mm |
| Max Width of Box | 400mm |
| Min Width of Box | 50mm |
| Max Height of Box | 120mm |
| Min Height of Box | 12mm |
| Speed | 20-40pcs/min |
| Power | 4.5kw |
| Air Pressure | ≧0.6Mpa |
| Power Supply | 380V/50Hz |
| Weight | 2000kg |
| Machine Size | L3000*W2400*H2600mm |
Packing and Shipping
Packaging by wooden case and shipping by containers.
