Product Details:
|
| Tape Type: | PET Tape | Voltage: | 220V/50Hz |
|---|---|---|---|
| Condition: | New | Warranty: | One Year |
| After-sales Service Provided: | Engineers Available To Service Machinery Overseas | Automatic Grade: | Automatic |
| Color: | Customized Color | Driven Type: | Electric&pneumatic |
| High Light: | fully automatic rigid box making machine,automatic rigid box machine,automatic gift box making machine |
||
Corner Pasting Machine / Automatic Corner Pasting Machine / Four Corner Pasting Machine / Gift Box
Automatic Rigid Box Corner Pasting Machine Catalog...
Production Features:
1.The machine adopts single arm press device and thermostatic temperature control system.
2.The machine can use various hot-melt adhesive tape, the width is usually 19mm. other width of tape have to special to make it.
3.The length of adhesive tape can be adjusted between 10-50mm length by once for the different boxes.
4.The machine simple operation, fast working speed30-90pcs/min, high production efficiency, high cost performance.
5 Boards feed from bottom, thus no need to stop the machine for adding boards.
6 Stepper motors feed hot melt tapes which are pasted onto 4 corners at the same time.
7. The mainshaft adopts servo motor to drive the gear guide rail, making sure every accurate movement.
8. Operated by touch screen, with both Chinese and English by one switch.
Other Product Recommend
Technical Parameter
| Model | WM-40A |
| Grey Board Thickness | 1-4mm |
| Max. length of box | 500mm |
| Min. length of box | 45mm |
| Max. width of box | 400mm |
| Min. width of box | 40mm |
| Max. height of box | 120mm |
| Min. height of box | 12mm |
| Speed | 30-90pcs/min |
| Power | 3.0kw |
| Air pressure | ≧0.6MPa |
| Power Supply | 220V/50Hz |
| Weight | 1000kg |
| Machine Size | L2000*W1000*H2000mm |
Rigid Box Product flew
Our Exhibitions
We attended at least three oversea exhibitions every year to show our products to clients, warmly welcome to visit our booth in the exhibitions.
Safety precautions
1. Before production, please wear labor protection equipment to ensure the health and safety of operators.
2. Please designate professionals to train on-the-job operation and maintenance equipment.
3. When problems are found, please solve them in time. We can't continue production without problems.
4. Compliance with safety precautions during production can prevent accidents and potential hazards.
5. Verify whether the equipment is in normal condition before the equipment is running, such as checking the air pressure, resetting the mould, etc.
6. The equipment can not touch any rotating parts and movable parts in the operation process, so as to avoid causing personal injury.
7. Keep all air passages open.
8. It is forbidden to touch the high-temperature head-mounted parts by hand after being heated by electricity.
9. No touch adjustment is allowed when the equipment is running.
