19mm 22mm Width Hot Melt PVC Corner Pasting Tape

Basic Information
Place of Origin: China
Brand Name: wellmark
Model Number: TS1 PET Tape
Minimum Order Quantity: 1728 rolls
Price: Negotiable
Packaging Details: carton and pallet
Delivery Time: 1-2days
Payment Terms: L/C, T/T
Supply Ability: 1 pallet per one week
Detail Information
Type: Box Packing Tape Material: PVC
Adhesive Type: Hot Melt Sample: Free
Length: 300m Width: 19mm,22mm
High Light:

Hot Melt Corner Pasting Tape


PVC Corner Pasting Tape


PVC Corner Pasting Hot Melt Tape

Product Description

Corner Pasting Tape / Hot Melt Tape / PVC Tape



Product Description


Boxes Corner Hot-melt Adhesive Tape is mainly used for fixing the four corners of rigid boxes such as boutique boxes, gift boxes, mobile phone boxes, shoeboxes and so on (material: yellow kraft paper, white kraft paper, PET) and supporting (Zhongke, Hongming, Zhengrun, Fuzhong Japan, EMMECI Italy, Wellmark ,etc.) the machine is Automatic Four Corner Pasting Machine and automatic and manual Box Corner Pasting Machine. It can also improve production efficiency with good quanlity boxes

This tape is uniformly sprayed on the PET substrate in a dustless environment with high temperature hot melt adhesive. The thickness of the PET substrate is 50um and the thickness of the hot melt adhesive is 20um. The total thickness of the tape is 70um. The width of the tape is usually 19MM, but it can also cut other width tapes according to customer's requirements. The total length is about 300m. Mainly used in all kinds of carton filler machine or automatic four-corner filler machine to stick the four corners of the box. After filler filler, the carton is stable, reliable and safe. Mainly used for high quality gift boxes.


Usage method

Control the temperature between 180 centidegree to 195 centidegree. Used on automatic/semi Auto case making machine, box corner pasting machine,box four sides forming machine, automatic box wrapper, automatic rigid box making machine and so on.




Product Name PET Tape for pasting box corner
Color Transparent
Glue Type Hot melt glue
Applicable Fields Printing and packaging; Gift boxes and so on
Equipment suited Various stick corner machine, box making machine; four corners machine ect..
Based Material PET
Size 1.9cm*300m
Weight 12KG per carton
Specifications 70um thickness,300 meters length,19mm width, 24 rolls per carton.


Work Shop Image


19mm 22mm Width Hot Melt PVC Corner Pasting Tape 0


Packing and Shipping


Packing by canton boxes, then put onto the pallets for shipping.

Hot Melt Tape For Automatic Four Corner Pasting Machine 4


Hot Melt Tape For Automatic Four Corner Pasting Machine 5
