Product Details:
|
| Type: | Gluing Machine | Condition: | New |
|---|---|---|---|
| Application: | Paper Gluing | Packaging Type: | Case |
| Packaging Material: | Wood | Automatic Grade: | Semi-Automatic |
| Driven Typ: | Electric | Voltage: | 380V |
| Power: | 7.5kw | Place Of Origin: | China (Mainland) |
| Brand Name: | Wellmark | Model Number: | WM-650C |
| Dimension(L*W*H): | 6800*1450*1300mm | Weight: | 1200kg |
| After-sales Service Provided: | Engineers Available To Service Machinery Overseas | Product Name: | Gluing Machine |
| Color: | Green And Grey | Usage: | Paper Gluing |
| Feeding Way: | Manual Feeding | Speed: | 7-40pcs/min |
| Warranty: | One Year | ||
| Highlight: | automatic paper gluing machine,automatic box gluing machine,automatic gluing machine |
||
Manual Feeding Gluing Machine with Convoyer Belt / Gluing Machine
Product Description
WM-650C Manual Feeding Gluing Machine is adopt s hot water circulation automatic washing machine, this machine has stable performance,low cost, high efficiency,use the hot melt materials, thus avoiding traditional latex box after shrinkag deformation and mold, and reduce the production loss, reduce the production cost and tissues for high-end mobile phone boxes, jewelry boxes, cosmetic boxes, gift boxes, watches boxes, high-grade wine boxes, hardcover boxes, CD boxes industry of plastic.
This machine has an indirect heating and temperature control system, which can be applied to the place where the working environment is low. The system models can be assembled into various forms of assembly line according to the needs of the product. This machine can be applied into folders, file boxes, clothing box, shoes box, hardcover and other products. This machine has high efficiency; adaptabolity, hot meltadhesive, glue, latex can be used. Variable speed, no wear, no deformation, feeding, high precision.
Other Product Recommend
Hot Melt Adhesive Jelly Glue / Hot Glue
TECHICAL PARAMETERS
| TECHICAL PARAMETERS | ||
| MODEL | WM-650C | WM-850C |
| WIDTH | W80-600MM | W80-800MM |
| PAPER THICKNESS | 80-200GSM | 80-200GSM |
| WORKING SPEED | 7-40PCS/MIN | 7-40PCS/MIN |
| POWER | 7.5KW | 7.5KW |
| AIR PRESSURE | 0.6-0.8MPa | 0.6-0.8MPa |
| VOLTAGE | 380V/50HZ | 380V/50HZ |
| MACHINE WEIGHT | 1000KG | 1200KG |
| MACHINE SIZE | 6800*1450*1300MM | 7800*1650*1300MM |
We provide 12 months warranty. During warranty, we provide free technical support and free normal spare parts for replacing, except for man-made damage.We can go to your country to debug machine when you have questions can not resolve,but you must pay 100usd/day to our engineer.
Look forward to long term cooperation with customers, we will make best service and aftersales service for all of our customers.
Gluing Machine is suitable for feeding and gluing the paper which is for making book cover, rigid box, set up box, etc.
It has the function of automatic temperature control and 24-hours timer.
The suction devices for the assembly lines prevent cover paper from curling and bubbling.
Hot melt adhesives (animal adhesives) are used for health and environmental protection ,and they also save cost because of the recycle system and the adjustable speeds .
