Automatic Die Cutting Machine For Paper Card Making

Automatic Die Cutting Machine For Paper Card Making
Automatic Die Cutting Machine For Paper Card Making Automatic Die Cutting Machine For Paper Card Making Automatic Die Cutting Machine For Paper Card Making Automatic Die Cutting Machine For Paper Card Making

Large Image :  Automatic Die Cutting Machine For Paper Card Making

Product Details:
Place of Origin: China
Brand Name: WELLMARK
Model Number: WM-1300B
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Standard Seaworthy Packing
Delivery Time: 25-30 working days after receive the deposit .
Payment Terms: T/T, L/C at sight
Supply Ability: 10 set per month

Automatic Die Cutting Machine For Paper Card Making

Description
Type: Packaging Machine Condition: New
Application: Applying To Die-cutting, Creasing, And Cold Embossing For Cartons, Paper Boxes And Paper Labels, Etc. Packaging Type: Case
Packaging Material: Wood Automatic Grade: Automatic
Voltage: 380V Power: 18KW
Place Of Origin: Guangdong, China (Mainland) Model Number: WM-1300B
Dimension(L*W*H): 5700×2300×2300mm Weight: 15Ton
After-sales Service Provided: Engineers Available To Service Machinery Overseas Max.Die-cutting Speed: 5000sheets/h
High Light:

auto die cutting machine

,

die cutting and creasing machine

,

automatic die cutter

Automatic Paper Die Cutting Machine For Paper Card Making





Product Description



WM-1300B Automatic die-cutting Machine is an ideal equipment to die cut and crease the paper, paper board packing material. It is easy to operate the machine with man machine interface with displaying the breakdown and frame locking system, digital displaying up-down of mold pressing. The cooling system of oil circulation decrease difference of hot and cold part of machine so as to reduce the number of rejects and extend the machine service life. Main electrical components are all world wide famous brands, Industry cooling system ensure the electric component durable and steady performance.





Technical Prameters



Model WM-1300B
Max. Die-cutting Speed 5000 sheets/h
Die-cutting Precision ±0.25mm
Max. Die-cutting Pressure 250T
Max. Paper Size 1320×950mm
Min. Paper Size 550×450mm
Max. Die-cutting Size 1310×940mm
Cardboard 200-2000g/㎡
Corrugated paper ≤6mm(max. thickness)
Total Power 18KW
Weight 15T
Dimensions 5700×2300×2300mm





Machine Features

1) It mainly suitable for high accuracy die cut requirement material such as 0.1~2mm cardboard, corrugated board less than 4mm
2) It is fast working speed, high safety, easy operation
3) It can stable feeding, die cutting and collecting the thin paper which thickness above 80gsm.
4) The feeder with 4 suction and 4 feeding makes paper feeding more smooth
5) Fully automatic non-stop paper feeding and stacking trolley improved the productivity.
6) With die cutting frame automatic lock design, high safety and convenient and simple operating.
7) Die cutting frame high strength and precision, frame backing plate adopt hard stainless steel, beautiful and durable.
8) Die cutting pad plate hardness HRC50~53, flatten and rusty proof, durable using.
9) Crank shaft, pendulum shaft, worm, etc are all imported alloy steel and precision finishing
10) Oil circulation cooling system improved the difference between heat part and cold part of machine, decrease the
rejects number and extend the parts service life.
11) Die cutting lift and backward adopt digital displaying, accuracy 0.001mm
12) Luxury appearance, acheived international standard







Machine Characteristics



1. Complete design, accurate installation, high stability, high security, low noise.

2. Adopt worm, worm gear, crankshaft transmission, high cutting pressure, high durability.

3. High precision intermittent mechanism, high cutting precision, running steadily.

4. Adopt European technology feeder, suction adjustable, steadily, precise, good paper applicability.

5. Non-stop feeding, pre-stacking and delivery device can shorten the auxiliary time, improve the efficiency.







Machine Parts Introduction



1. Paper Feeding part
Sheet suction feeder high speed and stable. Sheet separator is reliable, There are 4-8 separating suckers can suitable for various paper.
It have a vice feeding mechanism and vice feeding mechanism and vice feeding mechanism transition, which ensure continuous feed on-line.


2. Paper Tranfering Part
Sheet guide stable, location accurate. In the course of the running, sheet location can be adjusted..
Fix widen conveyer belt us adopted, operator can be adjusted.
Register system is push-pull system, which can be suitable for various paper without change.


3. Die-cutting and Creassing Part
New drive gear and servounit ensure high speed die cutting.
Overload protective system ensure that driving part and drive part separate when accident overload.
Pneuma-lock plate , air clutch.
Unique die cutting frame prevent from deflecting or separating.


4. Paper Delivery Part
Delivery is automatic and even.
On-line vice delivery raise the efficiency.
On-line sampling mechanism ensure sampling anytime

5.​ Electrical Control Part

Electurically control system adopt computer control, which ensure that feeding, guiding, die cutting and delivery automatic control and real-time detection.

Man-machine interface indication system will show working state, trouble position and shooting.
Safe guarden will alarm when accident, and automatic shut-down.







Our Services

1. Pre-Sales Service:
Inquiry and consulting support.
Sample testing support.
View our Factory.

2. After-Sales Service
Training how to install the machine, training how to use the machine.
Engineers available to service machinery overseas.

3. Warranty

We provide 12 months warranty. During warranty, we provide free technical support and free normal spare parts for replacing, except for man-made damage.We can go to your country to debug machine when you have questions can not resolve,but you must pay 100usd/day to our engineer.

Look forward to long term cooperation with customers, we will make best service and aftersales service for all of our customers.







Packaging & Shipping


1. The packing is confirm to export wooden case standard, strong and durable. The wooden case’s thickness is generally 1 cm.

2. In order to be waterproof, we usually use film to wrap machine.

3. We can handle shipping for customers too.
