Automatic Die Cutting Machine For Paper Box Creasing

Basic Information
Place of Origin: China
Brand Name: WELLMARK
Certification: CE
Model Number: WM-920
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Wooden case
Delivery Time: 10-20 work days
Payment Terms: L/C, T/T
Supply Ability: 1 set per two weeks
Detail Information
Warranty: One Year After-sales Service Provided: Engineers Available To Service Machinery Overseas
Condition: New Product Name: Automatic Paper Die Cutting Punching Machine Price
Function: Automatic Die-cutting Machine In Electric Field Name: Die Cutting Machine
Automatic Grade: Automatic Color: Requirement
High Light:

auto die cutting machine

,

cardboard die cutting machine


Product Description

Automatic Die Cutting Machine For Paper Box Creasing







Features



1. Complete design, accurate installation, high stability, high security, low noise.

2. Adopt worm, worm gear, crankshaft transmission, high cutting pressure, high durability.

3. High precision intermittent mechanism, high cutting precision, running steadily.

3. Adopt European technology feeder, suction adjustable, steadily, precise, good paper applicability.

4. Non-stop feeding, pre-stacking and delivery device can shorten the auxiliary time, improve the efficiency.

5. Automatic pressure adjust system, pressure digital display.

6. Human-friendly designed die frame and baseplate, makes installation, adjustment convenient.

7. Pneumatic die locking device, die frame fixed more steadily, accurately, time saving.



Product Description



WM-920 Automatic Die-cutting and Creasing Machine with stripping station is key equipment applying to die-cutting, creasing, and cold embossing for cartons, paper boxes and paper labels, etc. High-precision intermittent mechanism, pneumatic chase locking mechanism, air clutch, overload protector and special driving device, registration mechanism ensure smooth feeding, accurate registering and order delivery. Practical and reliable mechanisms such as pre-stack device, secondary feeding device, automatic timing lubricating device, etc. ensure the excellent performance of the machine.





Technical Parameter



Model WM-920
Max. Die-cutting Speed 8000 sheets/h
Die-cutting Precision ±0.1mm
Max. Die-cutting Pressure 200T
Max. Paper Size 920×670mm
Min. Paper Size 360×320mm
Max. Die-cutting Size 910×660mm
Cardboard 80-2000g/㎡
Corrugated paper ≤5mm (max. thickness)
Total Power 12.1KW
Weight 11T
Dimensions 4500×1870×2000mm



Die cutting and creasing part



1. Precise drive gears and servomechanism ensure the stable performance with high die cutting speed. When overpower occurs, overpower protection mechanism deflects driving mechanism and driven mechanism.

2. Pneumatic closed up mechanism makes the operation of change of plate easier and closed up stable.

3. Adjustable die cutting plate frame makes lockup of various sized plate more convenient.

4. High hardness die cutting steel plates are adopted to make themselves more durable. And 5+2(3+1) mm separated die cutting steel plates are co nvenient for storage.

5. Advanced imported pneumatic clutch braking system is safe and reliable. And its service life is longer.



Our Exhibitions



We attended at least three oversea exhibitions every year to show our products to clients, warmly welcome to visit our booth in the exhibitions.

Automatic Die Cutting Machine For Paper Box Creasing 0



Automatic Die Cutting Machine For Paper Box Creasing 1
