Product Details:
|
| Type: | Gluing Machine | Condition: | New |
|---|---|---|---|
| Application: | Apparel, Beverage, Chemical, Commodity, Food, Machinery & Hardware, Medical, Textiles | Driven Typ: | Electric |
| Voltage: | 380V | Power: | 7.5kw |
| Place Of Origin: | China (Mainland) | Brand Name: | Wellmark |
| Model Number: | WM-650A | Dimension(L*W*H): | 6800*1450*1300mm |
| Weight: | 1200kg | After-sales Service Provided: | Engineers Available To Service Machinery Overseas |
| Color: | Green And Grey | Usage: | Paper Gluing |
| Feeding Way: | Feeder Automaticly Continuesly Feeding | Speed: | 7-40pcs/min |
| Warranty: | One Year | ||
| Highlight: | automatic paper gluing machine,automatic box gluing machine,automatic gluing machine |
||
Automatic Gluing Machine For Cover Paper Gluing
Product Description
Automatic gluing machine is use for glue the paper for rigid box, paper box, hard cover, book cover, calendar , set up box and so on. This gluing machine is a transferring type of paper upper-side gluing equipment, combined with its own many-year experience about packing machinery, designed against the needs of the clients. it is characterized by rational structure, stable performance, convenient operation, easy replacement, and low labor intensity. it adopts heat fused adhesive powder to avoid traditional white emuision from shrinking and midew. It is an ideal equipment formedium and sized printing packing plants to make flow line production.
Product Features
1. Manual feeder gluing machine is suitable for gluing the paper which is for making book cover, rigid box, set up box, etc.
2. It has the function of gluing, automatic temperature control and 24-hours timer.
3. The draft fan under the assembly lines prevents cover paper from curling and bubbling.
4. Feeder absorption and feed are applied, which contribute to the characteristic of steady and quick paper conveyance.
5. Hot melt adhesives (animal adhesives) are used for health and environmental protection, and they also save cost because of the recycle system and the adjustable speeds.
Technical Parameters
| MODEL | WM-650A | WM-850A |
| WIDTH | W80-600MM | W80-800MM |
| PAPER THICKNESS | 80-200GSM | 80-200GSM |
| WORKING SPEED | 7-40PCS/MIN | 7-40PCS/MIN |
| POWER | 7.5KW | 7.5KW |
| AIR PRESSURE | 0.6-0.8MPa | 0.6-0.8MPa |
| VOLTAGE | 380V/50HZ | 380V/50HZ |
| MACHINE WEIGHT | 1200KG | 1400KG |
| MACHINE SIZE | 7800*1450*1300MM | 7800*1650*1300MM |
Other Product Recommend
Product Advantages
a. Feeder control accurate, only feed one piece paper per time
b. Special design make the glue in one temperature all the time
c. Glue evenly and thin
d. Automatic feeder feed paper, make high and stable productivity.
e. After glue, the paper will output on the conveyor belt, the belt with vacuum to make the paper close to it
f. Use imported bearings and electronic components, making stable and longer uselife.
g. Add a air container to make the air pressure in one level all the time, This will help to avoid damge machine because the unstable air pressure.
h. Special design for reuse of hot melt glue. Help to wave glue. Can adjust the speed.
I. Hot melt glue and white glue are both ok.
We provide 12 months warranty. During warranty, we provide free technical support and free normal spare parts for replacing, except for man-made damage.We can go to your country to debug machine when you have questions can not resolve,but you must pay 100usd/day to our engineer.
Look forward to long term cooperation with customers, we will make best service and aftersales service for all of our customers.
