Product Details:
|
| Type: | Gluing Machine | Condition: | New |
|---|---|---|---|
| Application: | Apparel, Beverage, Chemical, Commodity, Food, Machinery & Hardware, Medical, Textiles | Driven Typ: | Electric |
| Voltage: | 380V | Power: | 7.5kw |
| Place Of Origin: | China (Mainland) | Brand Name: | Wellmark |
| Model Number: | WM-850A | Dimension(L*W*H): | 7800*1650*1300mm |
| Weight: | 1400kg | After-sales Service Provided: | Engineers Available To Service Machinery Overseas |
| Color: | Green And Grey | Usage: | Paper Gluing |
| Feeding Way: | Feeder Automaticly Continuesly Feeding | Speed: | 7-40pcs/min |
| Warranty: | One Year | ||
| Highlight: | automatic paper gluing machine,automatic box gluing machine,automatic gluing machine |
||
Automatic Gluing Machine For Rigid Boxes Continuesly Feeding
Product Description
Automatic gluing machine (feeder) has the function of automatic feed paper and gluing, automatic temperature control and 24-hours timer. The suction devices for the assembly lines prevent powder paper curling and bubbling. Fedia paper absorption and feed are applied, characteristic of steady and quick paper conveyance. Hot melt adhesives (animal adhesives) are used for health and environmental protection on the basis of recycling to save costs at the speeds adjustable.
Product Features
1. Manual feeder gluing machine is suitable for gluing the paper which is for making book cover, rigid box, set up box, etc.
2. It has the function of gluing, automatic temperature control and 24-hours timer.
3. The draft fan under the assembly lines prevents cover paper from curling and bubbling.
4. Feeder absorption and feed are applied, which contribute to the characteristic of steady and quick paper conveyance.
5. Hot melt adhesives (animal adhesives) are used for health and environmental protection, and they also save cost because of the recycle system and the adjustable speeds.
Technical Parameters
| MODEL | WM-650A | WM-850A |
| WIDTH | W80-600MM | W80-800MM |
| PAPER THICKNESS | 80-200GSM | 80-200GSM |
| WORKING SPEED | 7-40PCS/MIN | 7-40PCS/MIN |
| POWER | 7.5KW | 7.5KW |
| AIR PRESSURE | 0.6-0.8MPa | 0.6-0.8MPa |
| VOLTAGE | 380V/50HZ | 380V/50HZ |
| MACHINE WEIGHT | 1200KG | 1400KG |
| MACHINE SIZE | 7800*1450*1300MM | 7800*1650*1300MM |
Other Product Recommend
Product Application
This machine has an indirect heating and temperature control system, which can be applied to the place where the working environment is low. The system models can be assembled into various forms of assembly line according to the needs of the product. This machine can be applied into folders, file boxes, clothing box, shoes box, hardcover and other products. This machine has high efficiency; adaptabolity, hot meltadhesive, glue, latex can be used. Variable speed, no wear, no deformation, feeding, high precision.
Our Services
We provide 12 months warranty. During warranty, we provide free technical support and free normal spare parts for replacing, except for man-made damage.We can go to your country to debug machine when you have questions can not resolve,but you must pay 100usd/day to our engineer.
Look forward to long term cooperation with customers, we will make best service and aftersales service for all of our customers.
Packaging & Shipping
1. The packing is confirm to export wooden case standard, strong and durable. The wooden case’s thickness is generally 1 cm.
2. In order to be waterproof, we usually use film to wrap machine.
3. We can handle shipping for customers too.
