Automatic Gluing Machine / Double Feeder Gluing Machine

Basic Information
Place of Origin: China
Brand Name: wellmark
Model Number: WM-1100D
Minimum Order Quantity: 1 SET
Price: Negotiable
Packaging Details: plywood case
Delivery Time: one week
Payment Terms: L/C, T/T
Supply Ability: 1 set per 20 working days
Detail Information
Product Name: Automatic Folder Gluing Machine Type: Gluing Machine
Name: Automatic Box Gluing Machine | Folder Gluer Machine Driven Type: Electric
After-sales Service Provided: Online Support Speed: 7-40pcs/min

Product Description

Automatic Gluing Machine / Double Feeder Gluing Machine



Product Features

1) Autoamtic sheet-fed front edge suction for various sheet sizes.
2) Adjustable rollers apply smooth glue coating on the sheet surface.
3) The circulating glue system with temperature controller assures.
4) Conveyor equipment with air-suction system to forward sheet flat and stably.
5) With ball bearing design of feed table, the sheets are conveyed.


Product Application



This machine has an indirect heating and temperature control system, which can be applied to the place where the working environment is low. The system models can be assembled into various forms of assembly line according to the needs of the product. This machine can be applied into folders, file boxes, clothing box, shoes box, hardcover and other products. This machine has high efficiency; adaptabolity, hot meltadhesive, glue, latex can be used. Variable speed, no wear, no deformation, feeding, high precision.



Feida Feeding Gluing Machine Automatic Gluing Machine for Box Wrapping Paper 0



Technical Parameter



Model WM-1100D
Width W80-1000mm
Paper Thickness 80-250gsm
Working Speed 6-36pcs/Min
Power 7.5KW
Air Pressure 0.6-0.8MPa
Voltage 380V/50Hz Three phase and four wire
Weight 1050Kg
Machine Size 7850 * 1950 * 1250mm



Packaging & Shipping



1. The packing is confirm to export wooden case standard, strong and durable. The wooden case’s thickness is generally 1 cm.

2. In order to be waterproof, we usually use film to wrap machine.

3. We can handle shipping for customers too.

Double Feeder Gluing Machine / Book Case Gluing Machine 1
