Product Details:
|
| Type: | Packaging Machine | Condition: | New |
|---|---|---|---|
| Application: | Applying To Die-cutting, Creasing, And Cold Embossing For Cartons, Paper Boxes And Paper Labels, Etc. | Packaging Type: | Case |
| Packaging Material: | Wood | Automatic Grade: | Automatic |
| Voltage: | 380V | Power: | 19.5KW |
| Place Of Origin: | Guangdong, China (Mainland) | Brand Name: | Wellmark |
| Model Number: | WM-1060 | Dimension(L*W*H): | 5850 * 2100 * 2300mm |
| Weight: | 15Ton | After-sales Service Provided: | Engineers Available To Service Machinery Overseas |
| Max.Die-cutting Speed: | 7500sheets/h | Max.Strpping Speed: | 6500sheets/h |
| Highlight: | auto die cutting machine,die cutting and creasing machine,automatic die cutter |
||
Automatic Die-Cutting and Creasing Machine for Paper and Paperboard
Product Description
WM-1060 automatic die-cutting & creasing machines can efficiently complete the die cutting and embossing of products, as well as maintaining the highest precision and product quality. The MHC seriesfull-automatic die-cutting & creasing machines are well equipped and almost can adapt to all die cutting requirements of paper products.
Electrical components and driving elements of internationally known brands are adopted to ensure die cutting precision and reliability of running. PLC monitors and displays the electric control system, which is convenient for fault diagnosis. Man-machine interface monitors machine state displaying running instructions, trouble location, troubleshooting to fully actualize man-machine communication.
Technical Prameters
| Model | WM-1600 |
| Max. Die-cutting Speed | 7500 sheets/h |
| Die-cutting Precision | ±0.1mm |
| Max. Die-cutting Pressure | 250T |
| Max. Paper Size | 1060×760mm |
| Min. Paper Size | 450×360mm |
| Max. Die-cutting Size | 1050×750mm |
| Paper Processed | |
| Cardboard | 80-2000g/㎡ |
| Corrugated paper | ≤5mm (max. thickness) |
| Total Power | 18KW |
| Weight | 14T |
| Dimensions | 4800×2100×2300mm |
Main features:
(1) Adopt nodular cast iron-QT500-7, the mainframe wallboard casting by special technology process, thus featuring by high strength, never deformation and ensure the safety of the mainframe wallboard.
(2) Adopt Taiwan-imported intermittent mechanism to ensure that the machine operates accurately and reduce the occurrence of failure rate.
(3) The whole machine all uses SKFNSK imported original bearing.
(4) The whole machine uses original parts imported from France Schneider, and Japanese OMRON, etc.
(5) Key parts of teeth row are imported from Japan.
(6) Die cutting accuracy reach to ±0.1mm, and the highest speed of machine reaches 7500 sheets/hours.
(7) The craft shaft is adopts Germany Ni-Cr-Mo metal steel, with high precision and will never deforms.
(8) Use the centerline positioning system to realize fast plate changing of worksheet.
(9) Die-cutting plate frame adopts auxiliary plate-installation device, to realize different of model machines can be use universal die-cutting plate.
(10) Equip with touch-screen operation interface in both Chinese and English.
Machine Parts Introduction
Automatic feeding device: The device use European technology strong suction head. 4 sucktion 5 deliver function, adjustable smooth, stable, according to paper style and different angle of bend to make adjustment for get wild range of application. 2 group of laser control device to avoid the collision, with unstop feeding systerm to improve work efficiency.
Die cutting: The casting made by high strength resin sand process, air clutch to drive the high precision worm and worm wheel to ensure less deformation when get die cutting stress, smooth running in high speed. High speed intermittent device drived Germany chain, aluminum alloy with special process, double location to ensure the precision. The frame, air lock device, turnover device to change the groups(optional) to get more easy for sesond mould change, concave-convex cutting, replace the mould, also save time and cost. Automatic pressure adjustment device(optional) to adjust the pressure more easy and controllable.
Feeding: Adopt synchronous transport, smooth running, feeding shelves with air spring can mke operation more easily. There are push, pull, dual-purpose type side gauge on the both of sides, with adjustable front gauge location device, imported laser location device to make location more precision. Also have empty sheet, skew sheet, double sheet control device to ensure the feeding precision, smooth, reduce the waste of paper, single point clutch function can make feeding and cutting seperation anytime or synchronous combining, it makes operation more easily.
Delivery: Adopt mechanical drive brush press paper device, with bidirectional blowing device to deliver paper smoothly. Set the Speed reduction or stop delivery after paper's full, also can choose unstop delivery with vice delivery device. Take sample with air control, make table for any number of piece paper, setting automatic stop after reach setting pieces function.
Others: The machines adopts imprted electrical parts, imported bearing. Internal and external librication, internal parts adopts oil circulation system and ecternal parts use PLC automatic contrl oil pump system to keep machine interface is easy for make operation, also have fault display function, can notice the fault with sound and light alarm to ge toubleshooting on time. The flash memory disk(USB) can upgrade system very easily.
