Product Details:
|
| Type: | Packaging Machine | Application: | Applying To Die-cutting, Creasing, And Cold Embossing For Cartons, Paper Boxes And Paper Labels, Etc. |
|---|---|---|---|
| Automatic Grade: | Automatic | Voltage: | 380V |
| Power: | 18KW | Model Number: | WM-1300B |
| Dimension(L*W*H): | 5700×2300×2300mm | Weight: | 15Ton |
| After-sales Service Provided: | Engineers Available To Service Machinery Overseas | Max.Die-cutting Speed: | 5000sheets/h |
| Highlight: | auto die cutting machine,die cutting and creasing machine,automatic die cutter |
||
Automatic Die-Cutting and Creasing Machine with Stripping Station
Product Description
WM-1300PB Automatic Die-cutting and Creasing Machine with stripping station is a special equipment applying to die-cutting of advanced coiorful boxes and cartons.The machine combines several advantages over many other die-cutters both at home and abroad.Gripper bars with high inten-sity are applicable to all kinds of cardboard paperboard and corrugated paper.Frontal,back and side registration mechanism ensures great precision of die-cutting.Other parts are adopted such as intermittent mechanism with high precision,air clutch,pneumatic locking mechanism,programmable controller and machine interface.The interface can display various digital information of machine such as working speed,amount of paper processed,total running time,etc.it is easy to eliminate troubles according to the display of trouble shooting.Transducer is adopted to control the main mptor in achieving steppless speed variation.The machine has a lot of sensors and safety-ensuring devices to guarantee the safety of operator and the environment.Frontal and back pressure can be adjusted separately.It is convenient to stop the machine by handy.It can also realize die-cutting without clipper margin.
Technical Prameters
| Model | WM-1300PT |
| Max. Die-cutting Speed | 5000 sheets/h |
| Die-cutting Precision | ±0.25mm |
| Max. Die-cutting Pressure | 250T |
| Max. Paper Size | 1320×950mm |
| Min. Paper Size | 550×450mm |
| Max. Die-cutting Size | 1310×940mm |
| Cardboard | 200-2000g/㎡ |
| Corrugated paper | ≤6mm(max. thickness) |
| Total Power | 18KW |
| Weight | 15T |
| Dimensions | 5700×2300×2300mm |
1) It mainly suitable for high accuracy die cut requirement material such as 0.1~2mm cardboard, corrugated board less than 4mm
2) It is fast working speed, high safety, easy operation
3) It can stable feeding, die cutting and collecting the thin paper which thickness above 80gsm.
4) The feeder with 4 suction and 4 feeding makes paper feeding more smooth
5) Fully automatic non-stop paper feeding and stacking trolley improved the productivity.
6) With die cutting frame automatic lock design, high safety and convenient and simple operating.
7) Die cutting frame high strength and precision, frame backing plate adopt hard stainless steel, beautiful and durable.
8) Die cutting pad plate hardness HRC50~53, flatten and rusty proof, durable using.
9) Crank shaft, pendulum shaft, worm, etc are all imported alloy steel and precision finishing
10) Oil circulation cooling system improved the difference between heat part and cold part of machine, decrease the
rejects number and extend the parts service life.
11) Die cutting lift and backward adopt digital displaying, accuracy 0.001mm
12) Luxury appearance, acheived international standard
Feeding Part
1. The feeding device is designed for feeding all kinds of sheet with high speed.
2. The secondary feeding mechanism can actualize non-stop constant feeding.
3. Reliable separating device and 4-8 suckers ensure better applicability of feeding.
4. Convenience for adjustment of pressure reed and hairbrush’s location ensures the reliable sheet separating and smooth feeding.
5 .Feeding pile manual transverse mobile device makes operation convenient and flexible
Conveying Part
1. Conveying is stable and locating is accurate. Sheet location can be adjusted in the course of running.
2. Side lay locating device of excellent performance ensures accurate location.
3. Side lay detection device adopts photoelectric control to ensure accurate detection.
4. Reduction gears when paper is into place reduce the rebound force when being conveyed fast, which ensure accurate location of thin paper at high speed.
Die Cutting and Creasing Part
1. Precise drive gears and servomechanism ensure the stable performance with high die cutting speed. When overpower occurs, overpower protection mechanism deflects driving mechanism and driven mechanism.
2. Pneumatic closed up mechanism makes the operation of change of plate easier and closed up stable.
3. Adjustable die cutting plate frame makes lockup of various sized plate more convenient.
4. High hardness die cutting steel plates are adopted to make themselves more durable. And 5+2(3+1) mm separated die cutting steel plates are convenient for storage.
5. Advanced imported pneumatic clutch braking system is safe and reliable. And its service life is longer.
Stripping Part
1. The motive power for stripping parts is offered directly by driving axis, reducing driving links and making driving more steady and reliable.
2. The stripping stand can be pulled out, which makes the installation of stripping plate easier.
3. Up frame, middle frame and down frame are adopted in stripping mechanism.
4. There are two stripping modes including needle mode and plate mode to be selected according to die cutting works. Operation of change of plate is convenient, location is accurate and running is smooth.
5. Convenient operation and high automatically reduce the labor intensity
Delivery Part
1. Delivery part with side even and back even devices ensures that paper delivery is tidy and orderly.
2. Extension hairbrush mechanism can stabilize the delivered sheets.
3. The automatic secondary delivery mechanism speeds up the efficiency of work by non-stop delivery.
4. Non-stop sampling mechanism can actualize the inspection of die cutting sheets at any moment.
We provide 12 months warranty. During warranty, we provide free technical support and free normal spare parts for replacing, except for man-made damage.We can go to your country to debug machine when you have questions can not resolve,but you must pay 100usd/day to our engineer.
Look forward to long term cooperation with customers, we will make best service and aftersales service for all of our customers.
1. The packing is confirm to export wooden case standard, strong and durable. The wooden case’s thickness is generally 1 cm.
2. In order to be waterproof, we usually use film to wrap machine.
3. We can handle shipping for customers too.
