Product Details:
|
| Automatic Grade: | Automatic | Condition: | New |
|---|---|---|---|
| Packaging Type: | Case | Driven Type: | Electric |
| After-sales Service Provided: | Engineers Available To Service Machinery Overseas | Warranty: | 1 Year |
| Type: | Hard Case Machine | Glue Type: | Hot Melt Glue |
| Highlight: | automatic hardcase maker,hardcase making machine,bookcase making machine |
||
Fully Automatic Hard Case Making Machine For Making All Kinds Of Hard Case
Product Advantage
1, the automatic shell machine generally adopts feida automatic paper feeding structure, the whole movement is pneumatic control, the structure is simple and reasonable.
2. The width adjustment of the stack platform and the paper platform adopts the center concentric adjustment, and the operation is simple without error.
3, the cardboard feeding table adopts linear guide rail, accurate.
4. There is an automatic stop device for the paperboard feeding table to reduce the rejection rate of good products.
5. The conveyor belt adopts high-power suction fan, which makes the paper transportation more stable and accurate.
6. The paper conveying and positioning system adopts imported high-precision photoelectric control, making the positioning of paper and paperboard more accurate and reliable.
7. The rear automatic four-side dismantling machine adopts unique automatic pressure Angle and blanking mechanism to ensure the qualified rate of finished products.
8. The automatic leather shell machine material collecting platform adopts the desktop stacking conveying and discharging, which is more convenient for material receiving.
Finished Picture
Other Product Recommend
Hot Animal Glue Use For Automatic Gluing Machine
Technical Parameter
|
Paper Wrap Size (L=Length,W=Width) |
Widest(W) | 630mm |
| Narrowest(W) | 100mm | |
| Longest(L) | 820mm | |
| Shortest(L) | 120mm | |
|
Hard Book Case Size L=Length W=Width |
Longest(L) | 800mm |
| Shortest(L) | 180mm | |
| Widest(W) | 450mm | |
| Narrowest(W) | 120mm | |
| Thickness of Paperboard(g/m2) | Thinnest(T) | 1.0mm -4.0mm |
|
Thickness of Paper(g/m2,) |
Range |
80g/m2-200g/m2 |
| Speed | ≤35pcs/min | |
| Air pressure | 6-8bar | |
| Voltage | 380V/50HZ | |
| Moter power | 18kw | |
| Heater power | 6kw | |
| Net Weight | 5800kgs | |
| Machine Overall Dimension | L9m×W4.3m×H2.2m | |
Packaging & Shipping
1. The packing is confirm to export wooden case standard, strong and durable. The wooden case’s thickness is generally 1 cm.
2. In order to be waterproof, we usually use film to wrap machine.
3. We can handle shipping for customers too.
