Product Details:
|
| Type: | Notching Machine | Condition: | New |
|---|---|---|---|
| Automatic Grad: | Automatic | Application: | Rigid Box Making And Hard Cover Making |
| Packaging Type: | Wood Case | Place Of Origin: | Guangdong, China (Mainland) |
| Highlight: | auto v grooving machine,grooving machine,automatic grooving machine |
||
Rigid Box Automatic Grooving Machine / Notching Machine
Automatic Grooving Machine catalog.pdf
Product Description
Automatic grooving machine is for notching various types and models of gift boxes and paperboard boxes to make a beautiful appearance, upgrading the products to meet an ideal effect.
All the deluxe boxes could not stand the outside grooves on the finished box bottom edge, thus, the inner groove could perfectly avoid this cosmetic issue.
Product Feature
1. Slot effect: no burrs ,no dust, V Groove surface is smooth.
2. Environmental protection and energy saving: the total power consumption is 2.0 kw.been cut V groove material can recycle in whole( the cost can equal to power cost plus cutting tool cost) and low noise.
3. Production efficiency:manual plate feeding speed 8 hours can produce about 10000 boxes.
4. Durable cutting tool:with special knife grinder (simple),grind a knife only need 2 minutes,the client may sharpen yourself.
5. Adjustable cutter angle: two pieces of independent blade and fixture,different angles without customized blades,machine can adjust itself ,different cardboard thickness without adjustment can be slotted,use very convenient.
Technical Parameters
| Model | WM-1200A |
| Roating speed | 30m /min |
| Power | 2.0KW/220V/50HZ/1Phase |
| Deep of groove | 1~4mm |
| Max. width of each group | 900 mm |
| Max. width of board | 800 mm |
| Feeder power | 0.18 KW |
| Speed of feeder | 0~180pcs/min(adjust) |
| Board specification | 120~430mm |
| Travel of feeder | 185mm |
| Power of conveyor belt | 0.18 KW |
| Dimension | L1780×W1680×H1480 mm |
Product Character
1. Each cutting blade could move left and right by itself.
2. Double sides position plate are adjustable. The can ensure the precision.
3. The belt press wheel could adjust the pressure of belt.
4. The counter is used for record the number of production.
5. The wheel is use for adjust grooving degree from 80-140.
6. Scrap remove equipment.
7. Special use knife grinder, usually grind one piece of cutting blade need 2 minutes only.
8. Cutting blade and holder.
9. Standby belt and 4kw adjustable speed Frequency converter.
Product Application
Grooving machine belong to the Gift box package production line equipment. The machine is special designed for notching V type groove, use for industry-cardboard, Ash-cardboard, MDF board and other several of cardboard, to make it suitable for box or other packaging making.
Suitable for High quality package, Gift Box, Jewelry boxes, Watch packaging, mobile phone boxes, wine boxes, Storage box, shirt and shoes boxes, make-up, toiletry boxes, biscuits and cakes boxes, note book cover, book shape boxes, hardcover, file folders, display, game boards, display stands, posters and calendars, etc.
We provide 12 months warranty. During warranty, we provide free technical support and free normal spare parts for replacing, except for man-made damage.We can go to your country to debug machine when you have questions can not resolve,but you must pay 100usd/day to our engineer.
Look forward to long term cooperation with customers, we will make best service and aftersales service for all of our customers.
